Transparent Level Gauge

Specifications:
1. Model: Reflex or Transparent
2. Connection Size: 1/2" , 3/4", 1 1/4, 1 1/2"
3. Connection Type: JIS 10K , ANSI 150LB
4. Max. Pressure: 250 kg/cm²
5. Max. Temperature: 240°C
6. Body Material: SUS304, SUS316
7. Cover Material: SUS304, SUS316
8. Valve Material: SUS304, SUS316
9. Gasket Material: Asbestos, Teflon

Reflex & Transparent Level Gauge is designed for measurement of liquid level in tanks under high pressure and temperature conditions. It consists of double flat glass mounted opposite to each other on a chamber. The glasses are held together by studs through cover plates. It is used for interface services or when the process is dirty or viscous. The chamber is available in a variety of metallurgy i.e. PP, CS, MS, SS304, SS316, SS 316L etc. The isolation valves can also be supplied in different metallurgy depending upon process fluid.

We are Leading Manufacturer, Supplier and Exporter of Reflex Level Gauges From Taiwan to Globally offered by us are designed to meet the specific functioning requirements of all types of pressure vessels, tanks as well as boilers. Precision designing of these industrial gauges permit them safe functioning & accurate reading standards of any liquid level. Further these reflex level gauges are assembled with pair of auto shut off ball check valve arrangement, that ensures in them maximum safety standards.
