Digital Meters
Specifications:
1. Analog Input: 2 Wire or 3 Wire Pt-100~400 'C / -150~800 'F
2. Accuracy : ± 0.05%Fs +2Counts at 23℃ ±3℃
3. Analog Output: 0~5VDC,0~10VDC, 4~20mA.
4. Response Time : ≦1Sec.
5. Zero Adjustable : Inside. With Zero offset.
6. Output Load : Current Mode : ≦350Ω Max,DC Voltage Mode : 10mA Max
7. Digital Output : Isolated RS-485 Modbus-RTU,9600,19200,38400 Baud Rate Selectable.
8. Relay contact capacity: SPDT AC 120V 5A, 250V 3A, DC 24V 3A.
9. Operation Power : AC 110/220V ± 15% 50/60Hz. DC 24V; 48V ±15%.
10. Operating Condition: -10℃ ~ +55℃ 20 ~ 95% RH Non Condensed.
11. Display Range: Super Red LED 4-1/2;0~19999 Counts, Display Range Programmer.
We are offering wide range of Digital Panel Meter. These digital panel meters are made from very high quality raw material which ensures hassle free work performance at its user end. Moreover, our entire range is available in different specifications, as per the requirement of client. Furthermore, these digital panel meters are widely finds its applications in various electrical sectors.
Following the Customer-oriented principle, we aims to innovate hi-tech products and provide comprehensive solutions continuously, and continue to offer qualified products and excellent services to its global customers.
Our successful strategy is reflected in the number of certifications, including ISO9001 and CE quality system certification, Software Enterprise certificate issued by National Information Department, and hi-tech company certificate issued by government, etc.
